| Scanner Type | Public/ Web | CDF (Continuous Document Feeding) / Simplex sheetfeed Two-way paper path (Straight path, U-turn path)
|
| ADF Capacity | Public/ Web | - |
| Scanning Colour Modes | Public/ Web | Colour, Greyscale, Monochrome, Automatic Detection (Colour / Greyscale / Monochrome) |
| Optical Resolution | Public/ Web | 600 dpi |
| Image Sensor Type | Public/ Web | CIS x 1 (Front) |
| Light Source | Public/ Web | 3 Colour LED (Red / Green / Blue) |
|
| Scanning Speed (A4 Portrait)
@ 200 / 300 dpi | Public/ Web | 5.2 seconds per page (Approx 12 ppm) |
| Auto Mode (default) | Public/ Web | 5.2 seconds per page (Approx 12 ppm) |
| Normal Mode
(Colour / Greyscale: 150 dpi, Monochrome: 300 dpi) | Public/ Web | 5.2 seconds per page (Approx 12 ppm) |
| Better Mode
(Colour / Greyscale: 200 dpi, Monochrome: 400 dpi) | Public/ Web | 5.2 seconds per page (Approx 12 ppm) |
| Best Mode
(Colour / Greyscale: 300 dpi, Monochrome: 600 dpi) | Public/ Web | 5.2 seconds per page (Approx 12 ppm) |
| Excellent Mode
(Colour / Greyscale: 600 dpi, Monochrome: 1200 dpi) | Public/ Web | 20.4 seconds per page (Approx 3 ppm) |
|
| Standard Sizes | Public/ Web | A4, A5, A6, B5, B6, Business Card, Post Card, Letter, Legal and Custom Sizes. Folded A3, B4 and Double Letter |
| Custom Sizes | Public/ Web | Minimum: 25.4 mm x 25.4 mm (1" x 1") Maximum: 216 mm x 360 mm (8.5" x 14.17") |
| Paper Sizes with optional Document Carrier Sheet | Public/ Web | All document sizes listed above |
| Paper Weight | Public/ Web | Straight Path: 52 g/m² to 209 g/m² (14 lb to 56 lb) U-turn Path: 52 g/m² to 80 g/m² (14 lb to 56 lb) |
| Long Page Scanning | Public/ Web | Maximum: 216 mm x 863 mm (8.5" x 34") |
| Card Scanning | Public/ Web | 0.76 mm or less (compliant with ISO7810 ID-1 Type) Includes embossed cards in landscape orientation. |
| Paper Feeding Orientation | Public/ Web | Front Side Up |
| Multifeed Detection | Public/ Web | - |
| ScanSnap Home
Image Processing Functions | Public/ Web | Automatic Colour Detection, Automatic Cropping, Automatic Deskew, Automatic Rotation, Blank Page Detection, Brightness (B&W Only), Deskew by Document Text, Document Title Extraction, Document Type Detection, Increase Text Contrast, JPEG Compression, Reduce Bleed-through, sRGB. |
| ScanSnap Home
Output Filetypes | Public/ Web | JPEG, PDF, Searchable PDF. Password PDF, PDF/A (Windows only) |
| Paper Separation Method | Public/ Web | - |
|
| Scanner USB Port | Public/ Web | USB 2.0 / 1.1 (Type Micro-B Connector) |
|
| Compliant to | Public/ Web | IEEE802.11b/g/n |
| Wi-Fi Frequency Band | Public/ Web | 2.4 GHz |
| Wi-Fi Connection Modes | Public/ Web | Access Point Connect Mode (Infrastructure Mode) Direct Connect Mode (Ad-hoc Mode) |
| Wi-Fi Security | Public/ Web | WEP (64bit / 128bit), WPA (TKIP / AES), WPA2 (AES), WPA-PSK (TKIP / AES), WPA2-PSK (AES) |
| Wi-Fi Protected Setup (WPS) | Public/ Web | WPS 2.0 |
|
| LCD Touchscreen | Public/ Web | - |
| Power Source | Public/ Web | Battery / USB Port
|
| Battery Type & Capacity | Public/ Web | Li-Ion Battery 3.7 V / 720 mAh 140 sheets full -> empty |
| Power Requirements | Public/ Web | 5V / 1.5A (x1 USB Port) 100V - 240V AC ±10 % (50 / 60 Hz) |
|
| Operating Mode | Public/ Web | 4.7 W or less |
| Sleep Mode | Public/ Web | 2.2 W or less |
| Standby Mode | Public/ Web | 0.3 W or less |
|
| Operating Temperature Range | Public/ Web | 5°C - 35°C (41°F - 95°F) |
| Operating Humidity Range | Public/ Web | 20% - 80% (non-condensing) |
| Device Colour | Public/ Web | Black / Silver |
| Device Dimensions (Width x Height x Depth) | Public/ Web | 273 x 47.5 x 36 (mm) 10.74" x 1.87" x 1.42" |
| Device Weight (approx) | Public/ Web | 400 g |
| Environmental & Regulatory Compliance | Public/ Web | ENERGY STAR® / RoHS |
| Driver | Public/ Web | ScanSnap specific driver Windows®: Does not support TWAIN / ISIS® macOS®: Does not support TWAIN |
| Included Software
(available via download) | Public/ Web | ScanSnap Home (All-in-one document management software/driver) ScanSnap Manager (Conventional driver) ABBYY FineReader for ScanSnap™ |
